Roll-fed 350 Automatic High Speed V Bottom Paper bag

Roll-fed 350 Automatic High Speed V Bottom Paper bag

350 Full automatic high speed sharp bottom paper bag making machine is suitable for varied primary and printed rolling paper, such as Kraft paper, slick paper, coated paper, medico paper and so on. It finishes all procession all in a time consisting: perforating, middle gluing, printed pattern calibration, tube forming, calibration snapping, bottom folding, bottom forming, and collect final product quantitatively. This machine operates easier, working more efficient, and performance more steadily. It is a fantastic machine for full paper bag, paper bag with window, leisure snack bag, bakery bag, fast food bag, dry fruit bag eco-bag and so on.

Model 350



Length of cutting bag 165-715mm
Bag length 160-710mm
Bag width 70-350mm
Insert size 20-120mm
Bag mouth height 15/20mm
Bag speed 50-600pcs/min
Paper feed width 160-960mm
Paper material diameter Φ1100mm
Inner diameter of paper Φ76mm
Paper material thickness 35-80g/m²
Working Air Current More than 0.12m³/ minutes,0.5-0.8MPa
Machine power 380V    3 phase 4 wire           32kw
Total weight 6500kg
Machine Dimesion 6800*2900*2000mm
Name Size Download
G350J-Full-Automatic-High-Speed-Sharp-Bottom-Paper-bag.pdf 533 KB Download
