1200TS Sheet-fed Paper Bag Making Machine

BSC Serial TS Model Paper Bag Making Machine

BSC serial include a wide choice of paper bag machine, the TS model is the fully automatic type paper bag making machine, is suitable for the mass bag production, it is the first choice of medium and top-grade handbag device. This product adopts mechanical, electricity, light, gas integration technologies, combines and uses the paper as raw material finishing: paper feeding position, die-cutting tube forming, gusset forming bottom opening, bottom cardboard inserting and bottom glutting automatic, Seamless viscose(hot melt adhesive), then compaction output adopt the PLC program control, frequency control to realize the integral multidimensional control, more centralized control and single point remote control operation. Our Product is character by good quality and high efficiency, its technology ranks leading level in similar products.

Main Electrical Components List

Size 18200mm*1800mm+4500mm*1800mm Weight 15T
Min. Paper Sheet Size 520mm*290mm Power 20kw
Max. Paper Sheet Size 1150mm*580mm Top-Card length 150mm – 410mm
Top-card width 20mm – 55mm Gusset 55mm – 180mm
Top-card Weight 200g – 400g Bottom-card weight 200g – 600g
Bottom-card width 160mm – 425mm Bottom edges space <2mm
Bottom-card height 60mm – 175mm Top-Card 2 pcs
Bag Width 160mm – 450mm Paper Weight 100g-350g
Bag Height 200mm – 450mm Speed 35-55pcs/min
Folding 25mm – 60mm Glue Cold & hot


Item Name Brand            Origin Model
Machine body BSC China
Vacuum pump ORION Japan CBX62-P-VB-03
Paper feeding system BSC China
Main motor Siemens Germany
Servo Panasonic Japan
Air cylinder AIRTAC Taiwan
Electric element Siemens Germany RXM2LB2BD
Inverter Panasonic Japan AVF200-0754
Hot melt system Buehnen Germany SH8070P
Water glue machine KEKI joint venture KPM-PJ-V2.4
Bearing NSK/HRB Japan/China
Name Size Download
BSC-Serial-TS-Model-Paper-Bag-Making-Machine.pdf 673 KB Download
